1500 lbs Electric Winches for ATV UTV

1500 lbs Electric Winches for ATV UTV

Rated line pull: 1500lbs( 680 kgs)
Motor :0.6kw, 0.8hp , 12V DC Permanent Magent
Gearing: 3-Stage planetary
Gear ratio: 103:1
Freespooling clutch: Cam activated
Wire rope: 5/32"×40'(4mmx12.2m)
Dimensions: L×W×H (276×143×154)
Drum Diameter: 1.5"(38mm)
Drum Length: 3" (76mm)
NW: 9.8KG
Meas: 330*250*250 (1pc)

Address

No.38 Dongbei Road, Dongqiao Town, Haishu District, Ningbo, China
Phone

0574-83082762
Email

sales@chimawinch.com

Model:
CMH1500-A

Product Description

Pull,Speed,Amperes,Volts(First Layer)

Line Pull(lbs./kgs)	Line Speed FPM(m/min)	Motor(Amps)
0	15ft(4.6m)	6
500(227)	10.8ft(3.3m)	27
1000(454)	6.9ft(2.1m)	44
1500(680)	4.92ft(1.5m）	65

Line Pull & Cable Length

Layer	Rated Line Pull(lbs./kgs)	Total Rope On Drum(ft/m)
1	1500(680)	(5.9)1.8
2	1227(557)	(13.4)4.1
3	937(425)	(21.6)6.6
4	900(408)	(30.5)9.3
5	850(386)	(40.0)12.2

CMH1500-A (Ordinary)-1

Electric Winches for ATV UTV

Packaging & Shipping

Packaging & Shipping (2)

Packaging & Shipping

Packaging & Shipping (3)
