6000 lbs Electric Winches

• Rated line Pull: 6000lbs(2727kgs)
• Meas: 48.5×19.5×46.5cm(1pc)
• Motor: 4.0kw,5.5hp, Series Wound
• Control: Remote switch 11.5ft(3 5m)lead
• Gear train: 3 Stage planetary
• Gear reduction ratio:235:1
• Clutch: sliding Ring Gear
• Braking Action: Automatic in-The Drum
• Drum size: Diameter 2.52"(64mm)Length 5.26"(134mm)
• Cable: 9/32"×79'(7.2mm×24m)
• Fairlead: 4-Way Roller Fairlead
• Remote Control: Include
• Battery Leads: 2 gauge,59"(1 5m)
• NW/GW: 28KG/32KG
• Overall: L×W×H
• dimensions: 16.54"×6.3"×8.35"(420×160×212mm)
• Mounting Bolt Pattern: 6.456±0.015"×4.50±0.010"(164×114.3mm)

地址

浙江省宁波市海曙区洞桥镇洞北路38号
电话

13375454218
邮箱

sales@chimawinch.com

Pull,Speed,Amperes,Volts(First Layer)

Line Pull(lbs./kgs)	Line Speed FPM(m/min)	Motor(Amps)
0	10.0ft(6.0m)	80
2000(907)	7.5ft(4.2m)	120
4000(1818）	4.9ft(3.2m)	210
6000(2727)	2.9ft(1.9m）	320
6000(2727)	6.5ft(2.0m)	320

Line Pull & Cable Length

Layer	Rated Line Pull(lbs./kgs)	Total Rope On Drum(ft/m)
1	6000(2727)	13.0(4.0)
2	4990(2265)	29.0(9.0)
3	4280(1490)	48.0(14.6)
4	3730(1690)	69.0(21.0)
5	3310(1500)	79.0(24.0)
